4. Preparation
Starting the engine
Insert the glow plug!
Prop up the model for starting so that the wheels hang freely in the air and that the main pinion
on the lower side does not get blocked!
- Open the lid of the tank and fill in the fuel.
- Use a special tank bottle, in order to avoid spilling.
Only use model fuel for R/C cars!
Never use gasoline or model plane fuel!
- Pull the starter cord several times slowly, in order to ingest fuel in the carburettor
- Keep doing this until no more air bubbles are seen in the fuel hose and the fuel just barely gets in
the carburettor.
NOTE!
Do not pull the starter cord all the way but rather to approximately 3/4 of its
length!
Determine the length of the starter cord by pulling slowly without ignition!
Never pull out the starter cord with force!
- Place a plug connector with fully charged start battery on the glow plug.
- Pull the starter cord with energy, until the engine starts up, while you hold the model firmly with
one hand.
- When the engines starts to run, let go of the starter cord and remove the plug connector again.
Leave the plug connector connected to the engine only briefly. Otherwise, the
glow plug could burn out prematurely.
Switch off engine
- Cut off the air supply to the carburettor.
- Block the exhaust pipe with a piece of cloth, or
- Stop the fly wheel of the engine on the lower side of the car body with a piece of cloth / with
gloves.
The fuel supply should not be disconnected as otherwise the engine could overheat.
NOTE!
If, after several unsuccessful start activities, the starter cord can only be actuated
with excessive use of power, too much fuel got into the combustion chamber and
the crankcase. The engine is "flooded". Refrain from further start trials and remo-
ve excess fuel in order to avoid damaging the starter cord and the engine!
For this purpose, proceed as follows:
- Carefully turn in the main nozzle needle clockwise, as far as it will go.
- Unscrew the glow plug and check its glow function
- Place a piece of cloth on the engine and pull the starter cord 5-6 times (3/4 of the length!):
Fuel is pumped out and evaporates.
- Insert the glow plug again and turn the main nozzle needle by three rotations anticlockwise.
- Repeat the start activity
If the engine does not start up, at the latest after 10 or 12 times, proceed as de-
scribed above or try to eliminate the problem with the help of the trouble shooting
table!
