4. Preparation
b) Tools and auxiliaries, check list for putting into operation
The Buggy Chassis „RAMBO Racing 7.5" is pre-assembled ready to run (RTR).
Before the first start, some basic adjustments must be carried out or checked and the necessary accessories and auxiliaries must be prepared.
Go through the various points of the check list one after the other, and your model is then ready to run.
Tuning measures on the chassis and/or the installation of another RC system necessitate various tools. The latter are listed below.
Tools
- Socket wrench 17 mm for the wheel nuts
- Flat spanner 5 mm and 5,5 mm
to set alignment and inclination
Allen key 2.5 mm to change the shock absorbers
-
- Allen wrench 1.5 mm for the
headless screws at the adjusting rings of the
throttle / brake and steering linkage and the
transverse stabilizer and for setting tzhe shift point of the two
speed transmission
- Allen key 1.5 mm for the grub screws on the
adjusting rings of the throttle/brake and steering
linkages and the transverse stabilizers (optional)
- Crosstip screwdriver
for all other screws on the chassis,
the casings of the differentials and the RC mounting plate
- Screwdriver for the throttle stop screw and the main
nozzle needle
The instructions specific to position front / back / right / left always refer to the
c)

Chassis mounting and placing the decorative labels

The fastening elements for the car body are already pre-assembled in the contents of the delivery of the Buggy Chassis „RAMBO Racing
7.5". Before installing the car body, the boreholes for the car body supports and antenna passage must be mounted. Use a special car body
drill.
Installing the car body
- Apply colored chalk or slow drying paint on the edges of the car body support and
- Place the car body as exactly as possible on the chassis.
- Remove the car body again and
- Drill holes into the car body at the places marked with paint (chalk) for the mounting parts of the car body.
- Place the car body and fasten the latter with the car body splints
- Determine the position of the antenna tube on the car body and
- Drill here also a hole for the antenna passage.
- Make openings for the starter cord, the tank shutter and the cooling head.
The car body of RAMBO Racing 7.5 is already cut and painted!
- The decorative patterns are glued on the outside of the car body.
- Moisten the car body and the decorative patterns with a light washing-up liquid before placing them.
This gives you some time to reposition the decorative patterns and to flatten air bubbles.
- Fine details such as window frames, door sections or borders can be drawn with conventional decorative strips or waterproof markers.
44
NOTE!
longitudinal axis of the vehicle in drive direction "forward"!
Auxiliaries
- Cable fastener
- Air filter oil
- Low viscosity machine oil for lubrication and
to protect the combustion chamber against corrosive
residues in the engine, after operation („After Run")
Check list for putting into operation
What must be done:
- Check alignment and tooth backlash of drive
- Function control of servos
- Check the range of the remote control transmitter
- Check basic carburettor setting
- Fill in fuel
- Let engine run
Operating Instructions 4WD GP BUGGY RAMBO RACING 7,54 RtR No. 3 51 85
No. 22 30 30
