B) Suspending The Rotor Head Control; C) Checking The Retainer Of The Rotor Blade - Reely PRO Bedienungsanleitung

Warning!
Always connect one accumulator only to the charging adapter. The simultaneous charging of
two accumulators is not admissible and may damage the charger.
During the charging procedure, place the LiPo battery on a fire-proof support or in an appropriate
clay container.
Never charge the rechargeable battery unattended.
The plug-in power pack is to be used in dry indoor locations only. It must not get damp or wet.
Never touch it when your hands are wet or damp. There is the risk of a fatal electric shock.

b) Suspending the rotor head control

• Once you have taken the model helicopter out of the
packaging, first attach the eyelet (1) of the control rod
on the top rotor.
Press the eyelet gently with your thumb onto the ball
head (2) until it snaps into place.
• Then twist the bottom eyelet so that it is at a 45° angle
to the top eyelet.

c) Checking the retainer of the rotor blade

• To allow the 4 rotor blades (1) to orientate themselves
at a 180° angle to each other during operation, the
screws of the 4 blade retainers (2) must not be too firmly
tightened.
• If you pitch the model helicopter by 90° to the side, the
rotor blades must be able to let slightly downward as
illustrated in the figure.
Figure 4
Figure 5
45
