Setting the EPA value for the steering system
• Turn the transmitter on. In the LCD of the transmitter
the operation mode display appears.
• Now press the set key (see fig. 1, no. 12) five times.
On the left side of the display "CH1" for the steering
servo lights up, the steering direction arrow to the
left and the default setting or the one that was last
programmed appears.
• To set the EPA value of the steering servo to the left,
press the DT1 button (see fig. 1, no, 3) within 5 sec-
onds.
If you push the button to the left, the number reduces
in 1% steps. This reduces the maximum angle of the
steering servo to both sides.
If you push the button to the right, the number in-
creases in 1% steps and the angle of the steering servo
towards the left is increased.
The admissible setting for the EPA value is between
5% and 120%.
• If you press the set key (see fig. 1, no. 12) again within
5 seconds after the last setting, the steering direc-
tion arrow changes from left to right and the default
value or the one you last programmed is displayed.
The procedure for setting of the end point to the right
is the same as for the left.
• Five seconds after the last activation of a button, the
value you last set is saved and the display returns to
the operation mode display.
58
Figure 15
