Functional description
The.RADEMACHER.DuoFern.RolloTube.I-line.Radio.series.of.tubular.motors.are.designed.
for.opening.and.closing.roller.shutters.and.awnings.
The.internal.DuoFern.interface.enables.the.motor.to.be.integrated.into.a.DuoFern.radio.
network,.making.it.possible.to.configure.and.control.many.automatic.functions.remotely.
with.the.help.of.a.DuoFern.transmitter.(e.g..the.DuoFern.central.operating.unit)..
An.additional.switch.can.be.connected.to.the.tubular.motor.locally.in.order.to.enable.
manual.operation.
These.tubular.motors.are.equipped.with.the.new.Safe-Drive.system.for.position.detection,.
torque.monitoring.and.obstacle.detection..The.drive's.compact.design.and.fully.automatic.
end.point.configuration.ensures.for.straightforward.and.convenient.installation..
The.RolloTube.I-line.Radio.series.impresses.in.daily.operation.with.automatic.roller.shutter.
compensation.as.well.as.the.blockage.and.obstacle.detection.system.(with.reversing.
function),.ensuring.maximum.safety.and.gentle.operation.
General tubular motor functions:
. ◆ Commissioning.with.a.single.run.command..Self-learning.motor.with.fully.automatic. .
. end.point.configuration.
. ◆ Safe-Drive.method.for.precise.positioning,.torque.monitoring.and.obstacle.detection.
. ◆ Blockage.and.obstacle.detection.including.reversing.function.
. ◆ Obstacle.detection.can.be.arbitrarily.configured.thanks.to.the.new.snap-in.FlexiClick. .
. system.
. ◆ Maintenance.free.end.points.thanks.to.automatic.shutter.length.compensation.system..
. ◆ Quick.and.easy.installation.thanks.to.the.new.shorter.design..
. ◆ Optionally.available:.. Universal.RT.ConfigTool.for.individual.configuration.of.the. .
. . . motor.parameters.
Short description of the DuoFern radio system
The. DuoFern. radio. system. enables. bidirectional. data. exchange. between. the. various.
participants.of.a.DuoFern.radio.network..All.of.the.switching.commands.from.the.DuoFern.
transmitter.(e.g..DuoFern.central.operating.unit).are.received.and.acknowledged.by.the.
DuoFern.components.(actuators./.sensors),.insofar.as.both.devices.are.interconnected.
i
Blockage detection function
The tubular motor stops and automatically shifts into the opposite
direction (reversing) in the event that an obstacle is detected while
opening (e.g. if a roller shutter is iced-up).
NOTE
Do.not.move.iced-up.roller.shutters.and.rectify.the.fault.or.remove.the.obstacle.
i
Obstacle detection function
The tubular motor stops and automatically shifts briefly in the opposite
direction (reversing) in the event that the roller shutter hits an obstacle
while closing.
Tubular motor functions in combination with DuoFern transmitters
DuoFern environmental sensor; Item no 3200 00 64
DuoFern manual central operating unit; Item no 3481 00 60
RolloTron Pro Comfort DuoFern; Item no 1523 45 11
DuoFern manual transmitter standard; Item no 3248 03 66
Manual.control.(on/off).
AUTO/MANU.-.switchover
Timed.program
Timer.on./.off
Random.function
Twilight.program.(mornings)
Twilight.program.(evenings)
Darkness.control...
(mornings.and.evenings).on./.off
Solar.program
Automatic.solar.function.on./.off
Set.solar.position
Wind.program
Automatic.wind.function.on./.off
Set.direction.of.rotation.for.wind
Rain.program
Automatic.rain.function.on./.off
Set.direction.of.rotation.for.rain
Set.ventilation.position
Set.direction.reversal
Start.connection.test
End.point.adjustment.radio.controlled
Radio.code.support..
(e..g..log.on.and.log.off.with.radio.code)
Requirements for correct obstacle detection:
. ◆ The.catch.with.freewheel.mechanism.must.be.mounted.(see.Fig..4.a,.page.38).
. ◆ The.roller.shutter.must.be.mounted.to.the.rotating.union.with.the.fastening.springs. .
. or.with.the.fixed.shaft.connector.
. ◆ Roller.shutters.must.always.run.vertically.in.the.guide.rails.of.the.window.
