Key to the overall view (Figure a)
(1). Counter.bearing.
(2). Ball.bearings
(3). Axle.pin.on.bearing.capsule
(4). Bearing.capsule
(5). Rotating.union
(6). Mounting.spring
(7). Retaining.clip
(8). Catch
(9). Tubular.motor
(10). Adapter
(11). Set.button.(transparent.with.LED)
(12). Drive.head
(13). Drive.end.bearing
(14). Retainer
(15). Motor.cable
(16). Controller.(e.g..external.switch)
(17). Roller.shutter.casing
(18). Limit.ring
(19). Drive.adapter
(20). Hook-in.brackets
Please note:
.
. Customer-specific.scope.of.delivery
After unpacking please check the following:
. ◆ Check.that.the.package.contents.matches.the.scope.of.delivery.listed.on.the.package..
. ◆ Check.that.the.motor.type.corresponds.to.the.specifications.on.the.type.plate.
