General safety instructions
Danger due to electric shock when working on all electrical systems.
. ◆ The.electrical.connection.for.the.tubular.motor.and.all.work.on.the.electrical.systems.
may.only.be.undertaken.by.an.authorised.qualified.electrician.and.in.accordance.with.the.
connection.diagrams.in.these.instructions,.see.pages.42/43/44.
. ◆ Carry.out.all.installation.and.connection.work.only.in.an.isolated,.deenergised.state.
Mortal danger in the event of failure to observe these instructions!
. ◆ Observe.the.regulations.regarding.installation.in.damp.rooms..
. ◆ Especially.observe.DIN.VDE.0100,.parts.701.and.702.when.installing.in.damp.rooms..
. These.regulations.contain.mandatory.protective.measures..
The use of defective equipment can lead to personal injury and damage
to property (electric shocks, short circuiting).
. ◆ Never.use.defective.or.damaged.equipment..
. ◆ Check.the.drive.and.mains.cable.beforehand.for.damage.
. ◆ Consult.our.customer.service.department.(see.page.56).in.the.event.that.you.discover. .
. damage.on.the.equipment.
According DIN EN 13659, it is necessary to determine that the movement
conditions for the shutters are maintained in accordance with EN 12045.
The. displacement. must. amount. to. at. least. 40. mm. on. the. lower. edge. in. the.
rolled-out. position. with. a. force. of. 150. N. in. the. upwards. direction.. In. doing. so,. .
it. must. be. ensured. that. the. extending. speed. of. the. shutters. for. the. final. .
0.4.m.is.less.than.0.2.m/s.
Potential risk to life and limb resulting from uncontrolled starting of
the drive.
Never. attempt. to. manually. stop. the. motor/shutters. in. the. event. of. uncontrolled.
movement..In.such.cases,.switch.off.all.power.to.the.drive.and.take.appropriate.safety.
precautions.to.prevent.unintentional.switching.on..Arrange.to.have.the.system.checked.
by.a.specialist.engineer.
i
Proper use / operational conditions
Only use the tubular motors for opening and closing roller shutters
and awnings.
IMPORTANT
. ◆ The.motor.cable.must.be.laid.on.the.inside.of.the.empty.tube.up.to.the.junction.box. .
. under.observation.of.local.electrical.regulations.
. ◆ Only.use.the.manufacturer's.original.parts.and.accessories.
Only use tubular motors which correspond to the local conditions in
terms of their output. Incorrectly dimensioned tubular motors can lead
to damage:
◆ An insufficiently dimensioned tubular motor can be damaged due
to overloading.
◆ An excessively dimensioned tubular motor can cause damage, for
example, to the roller shutters and roller shutter casing when
configuring the automatic end-point setting.
. Consult.a.specialist.dealer.when.selecting.the.tubular.motor.and.observe.our.tractive. .
. force.specifications.on.our.Website:.www.rademacher.de
i
Incorrect use
Never use the tubular motor:
For.systems.with.increased.safety-relevant.requirements.or.where.there.is.an.increased.risk.
of.accidents..Such.use.would.require.additional.safety.equipment..Observe.the.respective.
statutory.regulations.for.the.installation.of.such.systems.
34
Incorrect use leads to an increased risk of injury.
. ◆ Train.all.personnel.to.safely.use.the.tubular.motor.
. ◆ Do.not.allow.children.to.play.with.the.fixed.control.units.
. ◆ Do.not.allow.children.or.persons.with.limited.capabilities.to.use.the.fixed.control.units. .
. or.remote.control.systems.
For roller shutters:
. ◆ Watch.the.moving.roller.shutters.and.keep.other.people.away.from.the.area.until. .
. the.movement.has.completed.
. ◆ Undertake.all.cleaning.work.on.the.roller.shutters.with.the.equipment.disconnected. .
. from.the.mains.power.
For awning systems which can be operated out of sight of the operator:
. ◆ Awnings.may.not.be.operated.if.work.is.being.carried.out.nearby.(e.g..windows. .
. being.cleaned).
For automatically actuated awnings:
. ◆ Awnings.must.be.disconnected.from.the.power.supply.if.work.is.being.carried.out. .
. nearby.
Regular maintenance of awnings increases operational reliability.
. ◆ Check.the.awnings.regularly.for.poor.balance.or.damaged.lines.and.springs.
. ◆ Have.damaged.awnings.repaired.by.a.specialist.firm.
Contact with the drive housing can cause burns.
. ◆ The.tubular.motor.gets.hot.during.operation..Allow.the.motor.to.cool.down.prior.to.
undertaking.any.further.work.on.the.motor..
. ◆ Never.touch.the.hot.drive.housing.
Operating conditions
. ◆ A.230.V/50.Hz.power.supply,.together.with.a.site-provided.isolating.device.(fuse,. .
. MCB),.must.be.permanently.available.at.the.installation.location.
. ◆ The.installation.and.operation.of.the.DuoFern.radio.system.and.its.components.is. .
. only.permitted.for.those.systems.and.devices.where.a.malfunction.in.the.transmitter. .
. or.receiver.would.not.cause.a.danger.to.personnel.or.property.or.where.this.risk.is. .
. already.covered.by.other.safety.equipment.
Never use the DuoFern radio system or its components for:
systems.with.increased.safety-relevant.requirements.or.where.there.is.an.increased.risk.
of.accidents..Such.use.would.require.additional.safety.equipment..Observe.the.respective.
statutory.regulations.for.the.installation.of.such.systems.
EN
