Hypertherm HySpeed HT2000 Betriebsanleitung Seite 178

HT2000-Stromquelle
Teile-
Position nummer
029514
1 004136
2 004311
3 004312
4 004313
5 004314
6 015131
7 015132
8 015133
9 015015
10 015532
11 041152
12 075153
13 075156
14 075194
15 075217
16 075335
17 075347
18 075229
19 075351
20 075360
21 075361
22 009356
23 041145
24 029202
25 015134
26 075072
HySpeed HT2000 Betriebsanleitung
: Hochfrequenz- und Eingabe-/Ausgabe-Karten-Bausatz
Beschreibung
HF & I/O PCB SA Pwr Sup/RHF
Connector, cathode
Standoff, MAX200 Anode
Standoff, MAX200 Cathode
Spacer, .42ID X .750 X .50 lg
Block, MAX200 Cathode
Fitting, 3/8 Tube X 1/4 NPT
Fitting, 90, 3/8 Tube X 1/4 NPT
Ferrule, 3/8 OD Tube Delrin
Adapter, 90 1/4 NPT X #6
Street Elbow 1/4
Panel, MAX200 Output
Hexnut, 3/8-16, Finish, Brs
Hexnut, 1/2-20, Finish/Jam, Brs
Lkwshr, 3/8, Splitlock, Brz
Flwshr, 3/8, .390,.875,.063, Brs
M/S, 8-32 X 1/2, SL, Bin, Nyl
Bolt, 5/16 X 11/4, Hex, Brz
Bolt, 3/8-16 X 1 1/2, FTH, Hex, Brs
Bolt, 3/8-16 X 1, Hex, Brs
Flwshr, 5/16, .328,.520,.032, Brs
Flwshr, 3/8, .394, .625, .032, Brs
Coil, A.C.T., 8G THHN
PC BD Assy MAX200 I/O
Current Sensor SA
Insert, 3/8 OD X .062 Brass
M/S, 8-32 X 1/2
STANDARD-KOMPONENTEN
bestimmt für
T1
PCB8
CS1
Menge
1
1
1
1
1
1
1
1
2
2
1
1
10
1
9
2
3
1
1
1
1
2
1
1
1
2
6
9-17
20
