Connection of KHS CONTROL-PLUS flow measurement valve
6.2.2.6
(Figure 638 4G / 138 4G)
Connection of KHS CONTROL-PLUS volume flow measurement valve
14 15 17
Ill. 6.9: Schematic diagram of connection of KHS CONTROL-PLUS flow
measurement valve
Connection of KHS CONTROL-PLUS temperature sensor
Ill. 6.10: Schematic diagram of connection of KHS CONTROL-PLUS volume flow sensor
Note
Ill. 6.11: Schematic diagram of connection of KHS CONTROL-PLUS temperature sensor
Manual KHS Mini System Control MASTER
BR = +5V DC = 14
BU = Flow = 15
BK = GND = 17
KHS
Attention: The
CONTROL-PLUS
internal Pt 1000,
additional temperature measurement.
If no temperature measurement is
needed or a Pt 1000
insulate and protect the strands from
contact with the board.
GY = grey (green/yellow) = 19
W = white = 20
Attention:
To perform the
measurement through
CONTROL-PLUS, the jumper on the
board must be changed from 4-wire to
2-wire, see Photo 6.11.
Important comment:
During this measurement,
temperature measurement is falsified
through the line resistance. For 10m
line-length with 0.34mm²
section, the measurement falsification
can amount to approx. + 0.5°C.
12
has an
enabling an
connected,
temperature
the KHS-
the
cross-
