Terminal Resistance; Connection Of Terminal Resistor - Kemper KHS-Mini MASTER Einbau- Und Bedienungsanleitung

Example 2: Incorrect layout
Note:
Incorrect layout
Ill. 5.2 View of an impermissible layout variant, KHS Mini System Control -Master-
5.2

Terminal resistance

Variant 1
CAN bus
A
Variant 2
CAN bus
B
Ill. 5.3 Illustration of a CAN bus line with terminal resistor

5.3 Connection of terminal resistor

120 Ω
Ill. 5.4 Illustration of the terminal resistor
connection
Manual KHS Mini System Control MASTER
CAN bus
A
CAN bus
A
Note:
The 120
resistance must be installed
only in the
component (-SLAVE-) of a
CAN bus cable line. The
-MASTER- control does not
require
resistance.
Attention:
All KHS
-SLAVE- are supplied with a
120 Ω terminal resistor.
For non-terminal
controls, the resistor must be
removed!
6
Ω terminal
last control
a terminal
Mini controls
-SLAVE-
