Wiring instructions for components with electrical connection

This list of cables only shows examples of applications. The exact design of the cables
in questions must be carried out on site by the planner on the basis of the ambient
conditions (temperature, frequency, routing type, mechanical load).
Tab. 12.1 Wiring instructions for components with electrical connection
Designation
[-]
KHS VAV PLUS maximum
flow isolating ball valve with
spring reset servo drive (24 V)
KHS VAV maximum flow
isolating ball valve with servo
drive (24 V)
KHS VAV PLUS maximum
flow isolating ball valve with
spring reset servo drive
(230V)
KHS VAV maximum flow
isolating ball valve with servo
drive (230 V)
KHS free drain with overflow
sensor
Kemper CONTROL PLUS
Flow measurement valve
Vortex principle
Kemper CONTROL PLUS
Flow measurement valve
Vortex principle
KHS temperature sensor
fitting Pt 1000
Leakage water sensor
CAN bus cable
The application is based on
the ISO 11898 international
standard.
* Possible cable type for fixed routing, without mechanical load
** Shielded cable lead
According to VDE 0815: The specification of signal transmission cables with
respect to the diameter is specified in mm.
Manual KHS Mini System Control MASTER
Cable cross-section /
Art.-No.
[-]
686 01 015...032
2 x 2 x 0.80 mm **
(position feedback)
686 00 015...032
2 x 2 x 0.80 mm **
(position feedback)
686 05 015...032
686 04 015...032
688 00 020...032 2 x 2 x 0.80 mm **
4 x 2 x 0.80 mm **
138 4G 015...050
138 6G 015...050 4 x 2 x 0.80 mm **
628 0G 015...050
2 x 2 x 0.80 mm **
629 0G 015...050
620 00 00100 2 x 2 x 0.80 mm **
1 x 2 x 0.34 mm² **
1 x 2 x 0.50 mm² **
1 x 2 x 0.75 mm² **
Max. cable
diameter
[mm²] [mm]
3 x X mm²
(power supply) 150 (X=1.50)
+ 300 (X=2.50)
500 (X=4.00)
5 x X mm²
(power supply) 80 (X=1.50)
+ 150 (X=2.50)
250 (X=4.00)
3 x 1.50 mm²
5 x 1.50 mm²
42
Cable type*
length
[m] [-]
NYM-J
+
J-Y(ST)Y
NYM-J
+
J-Y(ST)Y
1000 NYM-J
1000 NYM-J
150 J-Y(ST)Y
300 J-Y(ST)Y
300 J-Y(ST)Y
1000 J-Y(ST)Y
500 J-Y(ST)Y
300
500 CAN bus cable
1000
