KNOWING YOUR NEW WAFFLE MAKER

1
2
3
3
5
7
1 THERMALLY INSULATED LID HANDLE - For opening and
closing the lid.
2 LID with floating lid hinge
3 DIE-CAST ALUMINIUM WAFFLE PLATE - In base and lid
with 2 waffle areas each: The PFOA-free non-stick coating
prevents the waffles from sticking.
4 STORAGE LOCKING CLIP - Keeps the lid locked to the base
for moving and storing the waffle maker.
EN
74
4
6
5 INTEGRATED MOAT - Avoids overflow of the waffle batter.
6 LOCK JUT - Engage the locking clip here.
7 STAINLESS STEEL HOUSING

CONTROL PANEL WITH CONTROL ELEMENTS

8 9
12
10 11
8 POWER BUTTON - For switching on or off.
9 MENU BUTTON - Press here to switch through the offered
programs.
10 TEXTURE BUTTON („CRISP EXTERIOR | MOIST
INTERIOR / UNIFORM TEXTURE") - For selecting the
consistency of your waffles.
DARK
LIGHT
1 2 3 4 5 6 7
14
CRISP EXTERIOR BELGIAN
15 16
MOIST INTERIOR
CLASSIC
CHOCOLATE
BUTTERMILK
17
CUSTOM

ACCESSORIES

18 MEASURING CUP - Use the integrated gradation for measuring out the batter for 1 waffle (approx. 100 -110 ml) or 2 waffles (approx.
200 -220 ml).
18
13
11 RESTART BUTTON - Starts operation with the current settings.
12 LCD-DISPLAY - Showing the current settings and the baking
time.
13 BROWNING CONTROL DIAL - 7 different settings allow to
customise the browning from light to dark.

LCD-DISPLAY

14 BROWNING INDICATOR DASHES - Depending on the set
value, the assigned series of dashes illuminates.
15 TEXTURE FUNCTION
16 PROGRAM MENU - The arrow indicates the currently selected
program.
17 BAKING TIME - The smart control software calculates the
required time for each baking cycle separately.
75
EN
