Cleaning and Maintenance

5.4 Removing the appliance door

Removing the oven door makes it much easier to access
and clean the oven interior. Proceed as follows:
• Open the door fully.
• Open the folding clamps (2) on the two door hinges (1)
completely forwards.
• Close the door carefully and then lift the door so that
the hinges come loose.
• Place the oven door on a soft surface to protect
the handle and front from damage before
To replace the door, proceed in reverse order
as described above, observing the following:
• Make sure that the hinge and hinge holder lugs are
aligned exactly.
• Do not forget to close the folding clamps so that they
are not damaged when closing the oven door.
5.5 Removing the slide-in racks
and telescopic pull-out rails
To facilitate cleaning of the slide-in racks and/or the side
walls of the cooking chamber, it is recommended
to always remove the slide-in racks from the oven.
Proceed as follows:
• Remove all accessories from the cooking chamber.
• Press the rack down slightly at the clamping point (3)
and swing it slightly inwards.
• Lift the rack slightly, pull it out of the anchoring holes
(4) and remove it from the cooking chamber.
• Before cleaning, remove the telescopic rails (5) if ne-
cessary by loosening their fixing screws.
To replace the grilles, proceed in reverse order
as described above, observing the following:
• Make sure that the grille snaps into place at the
clamping point and is firmly seated.
26
cleaning.
1
2
5
4
3
