1.2 Control panel

1
1 Power control (levels 1 - 6) for cooking zone 1
2 Power control (levels 1 - 6) for cooking zone 2
3 Power control (levels 1 - 6) for cooking zone 3
4 Power control (levels 1 - 6) for cooking zone 4
5 Function control
for setting the oven functions / heating modes
(see corresponding chapter)
6 Temperature control
to set the target temperature of the oven

1.3 Features and safety functions

Forced cooling of the oven front
The case cooling ensures low temperatures on control
panel, knob and oven door handle while the oven is in
operation.
The air exits between the oven door and control panel.
Caution!
Risk of burns!
Other oven components and accessories
become hot during operation.
Use potholders or similar to avoid burns!
7
2 5
8
6
7 Power control lamp
lights up when one or more of the controllers
for cooking zone power levels
is / are not in the off position.
8 Temperature control lamp
lights up during the heating process and goes out
when the set target temperature is reached.
Note: When the cooking chamber temperature drops,
the heating process will start again to maintain the
temperature. The lamp also will light up during
heating then.
Overheating protection
To prevent damage to the appliance, a built-in temperature
sensor monitors the temperature inside the hob.
If the temperature is too high, the hob will switch off
automatically.
Residual heat warning for cooking zones
If a cooking zone is still too hot to touch after operation,
this is indicated by the corresponding residual heat
indicator.
Caution!
Risk of burns!
To avoid burning yourself, do not touch cooking
zones whose residual heat indicator is still lit.
Product Overview
3 4
11
