Installation
Inserting and fixing the hob
• Place the hob on a stable, smooth surface
(e.g. use the packaging as a base).
Make sure that no pressure is exerted on the
elements protruding from the hob.
• Attach the four retaining brackets to the hob
as shown in the illustration.
• Check the hob seal for damage and correct positio-
ning on the hob.
• Insert the hob with the cables first into the prepared
cut-out in the worktop.
32
5
2
1
4
3
2
4 1
6
1 Screw (ST 3.9 × 6)
2 Retaining bracket
3 Screw hole
4 Base of the hob
5 Glass ceramic cooking surface
6 Worktop
