Product Overview

1. Product Overview

1.1 Description of the appliance

Hob
1
2
Oven and appliance front
6
8
7
9
15
16
13
14
10
4
3
5
12
5
4
11
3
2
1
10
1 Cooking zone 1
Ø 165 mm, 1200 W
2 Cooking zone 2
Ø 200 mm, 1800 W
3 Cooking zone 3
Ø 165 mm, 1200 W
4 Cooking zone 4
Ø 200 mm, 1800 W
5 Residual heat indicators
light up when the respective cooking zone
is too hot to touch and go out when it has
cooled down to an acceptable temperature.
6 Control panel
(see following section)
7 Oven door
8 Door handle
9 Window
10 Cooking chamber
11 Slide-in rack
(Counting from bottom to top)
12 Oven lamp
13 Fan
14 Lower heating element for bottom heat
(invisible under the cooking chamber floor)
15 Upper, outer heating element for top heat
16 Grill element
