Functional description
3.2

Switching on

The INVERTIG.PRO COMPACT welding unit is switched on at the main switch.
All LEDs light up for approximately 1 second. Then the digital display shows the
machine type and the program number for approximately 3 seconds. After these
3 seconds, all of the settings of the most recent welding procedure are scrolled
through one after the other and the values that were set are displayed. Of
course, this procedure can be interrupted at any time. This is carried out by
pressing an operating element or a torch button. The welding unit is now ready
for operation.
3.3

Special features of the operating panel

The active processor control supports you to ensure that operation is quicker and
easier.
All of the set parameters remain saved in the unit when it is switched off at the
main switch. When it is restarted, the parameters are set that were used for the
most recent welding procedure. To ensure that any changes you make to these
parameters also remain available when the machine is switched off you must
ignite the arc.
Only the currently required parameters are displayed, for example, when MMA
welding, TIG parameters like 2/4-step, HF on/off etc are suppressed. The same
applies to the frequency and balance parameters when direct current welding.
After switching on the machine, all settings are scrolled through one after another
and the values set are then displayed. This provides the necessary overview. Of
course, this procedure can be interrupted at any time. This is carried out by
pressing an operating element or a torch button.
If neither the rotating button or button is used within 20 seconds, the machine
automatically jumps back to welding current l1. This ensures that your basis state
always displays the most important value, welding current l1 and the same
starting point for operation.
