VIPA System 200V Handbuch Seite 88

Teil 3 Einsatz
16bit Error Value
Digital outputs
Index Sub- Name
Index
0x6307 0x00 16bit digital
input block
0x01 1st output
block
... ...
0x24 36th output
block
32bit Digital
outputs
Index Sub- Name
Index
0x6320 0x00 32bit digital
input block
0x01 1st output
block
... ...
0x12 18th output
block
3-50
Type
Unsigned8
Unsigned16 rw
...
Unsigned16 rw
Vorausgesetzt der entsprechende ErrorMode ist aktiviert, setzen Geräte-
fehler den Ausgang auf den Wert, der durch dieses Objekt definiert wird.
Type Attr.
Unsigned8 ro
Unsigned32 rw
... ...
Unsigned32 rw
Attr. Map. Default value
ro N Depending on
the compo-
nents fitted
N 0x0000
... ... ...
N 0x0000
Map. Default value
N Depending on
the compo-
nents fitted
N
... ...
N
HB97D - IM - RD_253-1CAxx - Rev. 14/21
Handbuch VIPA System 200V
Meaning
Number of available digital
16bit output blocks
1st error value digital output
block
...
36th error value digital
output block
Meaning
Number of available digital
32bit output blocks
1st digital output block
...
18th digital output block
