VIPA System 200V Handbuch Seite 86

Teil 3 Einsatz
8bit Error Value
Digital outputs
Index Sub- Name
Index
0x6207 0x00 8bit digital
output block
0x01 1st output
block
... ...
0x48 72nd output
block
16bit Digital
outputs
Index Sub- Name
Index
0x6300 0x00 16bit digital
input block
0x01 1st output
block
... ...
0x24 36th output
block
3-48
Type
Unsigned8
Unsigned8
...
Unsigned8
Vorausgesetzt der Error Mode ist aktiviert, wird im Fehlerfall der hier
vorgegebene Wert übernommen.
Type
Unsigned8
Unsigned16 rw
...
Unsigned16 rw
Attr. Map. Default value
ro N Depending on
the compo-
nents fitted
rw N 0x00
... ... ...
rw N 0x00
Attr. Map. Default value
ro N Depending on
the compo-
nents fitted
N
... ... ...
N
HB97D - IM - RD_253-1CAxx - Rev. 14/21
Handbuch VIPA System 200V
Meaning
Number of available digital
8bit output blocks
1st error value digital output
block
...
72nd error value digital
output block
Meaning
Number of available digital
16bit output blocks
1st digital output block
...
36th digital output block
