Zipro Rook Bedienungsanleitung Seite 18

MOBILE APP BLUETOOTH PAIRING
The computer is compatible with iConsole+ Training.
Start your training and enjoy new possibilities:
•
Download the app.
•
Enable Bluetooth on your mobile device.
• Start the app and select the ZIPRO device you want to pair.
• When ZIPRO is connected with the app, the computer is turned off and the screen goes blank. From now on, you control ZIPRO through your
mobile device.
iOS compatibility: version 11.0 watchOS 4.2 or higher. iPhone, iPad, and iPod Touch compatibility. Android compatibility: version 5.0 or higher
Made for iPod, Made for iPhone, and Made for iPad mean the the electronic devices meet Apple standards and were designed to communicate with iPod, iPhone, or iPad. Apple is not
liable for the operation of the devices. Use of the devices may affect the performance of the wireless network.
iPad, iPhone, iPod Classic, iPod Nano, iPod Shuffle, and iPod Touch are Apple Inc. trademarks
TRAINING AND PHASES
The use of the device is very beneficial. It will improve your physical
condition, strengthen your muscles, and when combined with the right
diet, it will help burn excess fat tissue.
1. WARM-UP
This phase improves blood circulation in the whole body and prepares
the muscles for intensive work. It reduces the risk of cramps and
injuries. It is advisable to do some stretching exercises as shown below.
If you feel pain, stop exercising or reduce the extent of the move.
STRETCHING INNER THIGH MUSCLES
Sit on a flat surface with your legs bent and knees pointing outwards.
Put feet soles together and get them as close to you as possible.
Slightly push the knees downwards and hold for 15 seconds.
THIGH STRETCHING
Sit on a flat surface. Straighten the right leg and press the sole of the
left foot against the tight. Stretch your right arm towards the toes of the
right leg as far as possible. Hold for 15 seconds. Repeat for the left leg.
HEAD SIDE-TO-SIDE
Keep your head straight looking forwards. Keep your shoulders still,
and rotate the head right. Return your head so that you are looking
straight. Next, rotate it left and back to the starting point.
SHOULDERS UP-AND-DOWN
Lift the left hand as high as possible and hold for a few seconds. Repeat
for the right hand.
ACHILLES TENDON STRETCHING
Stand facing a wall. Extend the left foot forward and bend the knee a
little. Keep your right leg straight and back, with the heel on the
ground. Keep both heels flat on the ground and push your hips towards
TROUBLESHOOTING
CAUTION! Opening the housing of the device without a prior contact with a manufacturer's service voids the warranty. If you suspect a failure that requires
the housing to be opened, contact manufacturer's service.
Error description Possible causes
The device rocks to sides The device was placed on an uneven surface.
There is an object disrupting the balance under the base
of the device.
The bases have not be assembled correctly.
Caps on the base have not been installed and levelled
correctly.
The saddle or handlebar sway Bolts and knobs of the saddle column or handlebar
column have not been tightened.
Noise during use Incorrectly tightened elements.
Slight humming noise may be heard during operation due to the inertial movement of the flywheel caused by the
nature of the structure. It does not affect the operation of the device. Any possible humming noises heard when
rotating the pedals backwards occur for technical reasons and have no negative consequences.
Noise and uneven operation Bearings damaged.
Lack of appropriate Computer cable connected incorrectly.
resistance during training
Drive belt loose.
The distance between the flywheel and
the magnets increased.
Voltage regulator damaged.
No Bluetooth connection Bluetooth connectivity issues.
--- Grip not work correctly.
E-1 The device receives no input while measuring the user's
body fat.
the wall. Hold for 30 seconds. Repeat with the right leg extended.
Remember not to arch your back during the exercise.
BENDS
Stand up with your legs together. Bend forwards trying to get your
chest as close to the knees as possible. Hold for 15 seconds. Remember
not to bend the knees.
2. EXERCISE PHASE
This is the exercise proper. Maintain your own pace to reach the heart
rate appropriate for your age as shown in the chart below.
3. RELAXATION PHASE
This phase helps steady the circulation and relax the muscles. It is
identical to the warm-up phase. Remember not to strain your muscles.
Solution
Place the device on an even surface.
Remove the object that upsets the balance.
Assembly the bases correctly.
Level the caps on the rear base.
Assembly the rear base correctly.
Level the caps on the rear base.
Tighten the bolts and knob of the saddle or handlebar
column.
Contact the manufacturer's service.
Contact the manufacturer's service.
Connect the cable correctly as per the assembly manual.
Contact the manufacturer's service.
Contact the manufacturer's service.
Contact the manufacturer's service.
Enable Bluetooth on your mobile device. Pair your
mobile device with ZIPRO.
Contact the manufacturer's service.
Keep both hands on the pulse sensors during the
measurement.
EN
18
