5.1 Remarks

In order to perform the functions marked (*), in the case of transmitters, the trans-
mitter connection adapter must be used (see figure on page 6, no. 9) fitted to the
connector (no. 8) for that purpose, while in the case of smartcards, the smartcard
connection slot (no. 10) must be used, inserting the card with the chip downwards
and facing the operator in order for it to meet up with the contacts fitted in the
mouth of the connector, as shown in the following diagram. In the case of proximity
keys (see figure page 7) use the Interface provided for this purpose.

5.2 Read Transmitter Menu (*)

This menu makes it possible to read the code contained in a transmitter.
It is accessed via Main Menu/Transmitter.
Once selected, press
Transmitter Menu/Read Transmitter will appear.
Once selected, press
Press Transmit. Will appear.
Connect the transmitter and press the button.

5.3 Read Smartcard Menu

This menu makes it possible to read the code contained in a smartcard.
It is accessed via
Main Menu/Smartcard.
Once selected, press
Read SmartCard will appear.
Once selected, press
Insert SmartCard will appear.
Insert the smartcard.
and
and the message
and
and the message
51
General functions
