MANAGER+DCS 3.0X I
To create the installation, proceed as follows:
Switch off the power supply to the receiver apparatus (Micro-Receiver, Single-
Channel Receiver, Control Panel Receiver Card, Mini-A.C. or Maxi-A.C.) and re-
move the corresponding memory card. (Consult the manual of the receiver).
In the MANAGER+DCS, insert the memory cartridge into the corresponding slot
(see figure on page 6, no. 3), the transmitter adapter (9) in slot number 8, and the
memory card in slot number 4 in the case of a Receiver or Mini-A.C. or in slot num-
ber 5 in the case of a Maxi-A.C.

• Installing a Receiver

If the type of receiver element to be used is a Micro-
Receiver, a Single-Channel Receiver or a Control Panel
Receiver Card, select the Receiver menu using the direc-
tion keys or .
Once selected, press . The following message will ap-
pear:
Press 1 or 2 depending on the type of memory to be used,
and the following screen will immediately appear
Press again. The following message will appear:
Press the and keys simultaneously. A message
will appear on the screen requesting the number of trans-
mitters to be stored.
Enter the quantity by means of the numerical keys (e.g. 3).
Press . The following message will appear:
Insert the transmitter into the transmitter connection adapter (see figure on page
6, no. 9) and press any button of the transmitter.
