MANAGER+DCS 3.0X I
3.2 Creating the installation in the receiver unit and
storing it in the Portable Programmer
(Recommended option)
In order to create an installation in the receiver unit, the instructions accompanying
each of the models must be followed.
Once the programming of the receiver unit is completed, switch it off and remove
the corresponding memory card.
Insert the memory card into the corresponding connector of the Portable Program-
mer (see figure on page 6, nos. 4 and 5).
Set the power switch (see figure on page 6, no. 6) to ON. The
following message will appear on the screen and a long "beep"
will be emitted.
The Portable Programmer will now request the password. This consists of 6 fig-
ures: if fewer figures are entered, the Portable Programmer will interpret the entry
as erroneous: that is, to use the number 9 as the password, the value 000009 must
be entered. The password pre-set in the factory is always 000000.
Each time a figure of the password is pressed, an asterisk
* appears in the display and a "beep" is emitted.
Once the password is correctly entered, it must be validated by pressing
event of error, it can be deleted before validation by pressing the key
If an erroneous password is entered, the following message
will appear on the screen:
Once the password has been correctly entered, the screen
will display Main Menu/Transmitter.
Both the main menu and the submenus are of the rotary type, which means that
the various options can be accessed by pressing the direction keys
To facilitate the search for the options of each menu, section 1.4, Menu Tree,
shows an exploded diagram of the menus (pages 8 and 9).
Press the key until the screen shows the type of receiver element (Receiver,
Mini-A.C. or Maxi-A.C.) required for the installation.

• Installing a Receiver

If the type of receiver element to be used is a Micro-
Receiver, a Single-Channel Receiver or a Control Panel
Receiver Card, select the Receiver menu.
Press . The screen will show
Press 1 or 2 depending on the type of memory that is go-
ing to be used. Once selected, press
Menu/Edit will appear on the screen.
. The Receiver
40
. In the
.
or .
