Creating installations
All of the examples contained in this manual are based on transmitters. For installations
with smartcards or proximity keys, the steps to be followed are similar.
3.1 Creating the installation in the Portable Programmer
and storing it in the receiver unit
There are two ways of creating an installation in the MANAGER+DCS and then entering
it into the receiver: by applying the code stored in the transmitters, or by generating the
codes in the MANAGER+DCS and then storing them in the transmitters.
Set the power switch (see figure on page 6, no. 6) to ON.
The following message will appear on the screen and a
long "beep" will be emitted.
The Portable Programmer will now request the password. This consists of 6 fig-
ures: if fewer figures are entered, the Portable Programmer will interpret the entry
as erroneous: that is, to use the number 9 as the password, the value 000009 must
be entered. The factory pre-set password is always 000000.
Each time a figure of the password is pressed, an asterisk
(*) appears in the display and a "beep" is emitted.
Once the password is correctly entered, it must be validated by pressing . In the
event of error, it can be deleted before validation by pressing the key .
If an erroneous password is entered, the following mes-
sage will appear on the screen:
Once the password has been correctly entered, the screen
will display Main Menu/Transmitter.
Both the main menu and the submenus are of the rotary type, which means that
the various options can be accessed by pressing the direction keys or .
To facilitate the search for the options of each menu, section Menu Tree, shows a
blown up diagram of the menus (pages 8 and 9).
Press the key until the screen shows the type of receiver element (Receiver,
Mini-A.C. or Maxi-A.C.) required for the installation.
3.1.1

Using the code of the transmitter / smartcard / proximity key

All of the transmitters, smartcards and proximity keys have a pre-stored code. In
the case of transmitters, this is shown on the label on the rear of the unit and in the
booklet included in the packaging. The code of the smartcards, on the other hand,
is not stored anywhere: to view it, use the Read Card command of the Portable
Programmer. In proximity keys, this code is indicated on the label on the rear of the
packaging.
27
