Flexible Lead Cover; Electrical Accessories - Assa Abloy OneSystem N7 Serie Montageanleitung

Accessories

Flexible lead cover

Identifier
effeff – flexible
lead cover
10312-10
effeff – flexible
lead cover
10312-20
effeff – flexible
lead cover
10314-10
effeff – flexible
lead cover
10314-20

Electrical accessories

Identifier
Mains adapter
1003-24-1
Cable
OneSystem IO
module N5950
Description
Concealed installation in the
door frame
Concealed installation in the
door frame, with integrated
cable tracking
Concealed installation in the door
frame with clamp plug connection
on both sides and break-proof
flex cable
Concealed installation in the door
frame with clamp plug connection
on both sides and break-proof
flex cable
Description
Power supply 24 V / 1 A contin-
uous current stabilised output
voltage
For installation
· in distribution box or
· on top-hat rail
The maximum cable length
depends on the wire cross-section
and the output power on the mains
adapter ("Technical data", page 96)
Universal Interconnectivity Inter-
face: For provision of additional
functions such as monitoring con-
tacts, time settings and additional
door contacts
Order number
1 0 3 1 2 – 1 0 – – – – – 0 0
1 0 3 1 2 – 2 0 – – – – – 0 0
1 0 3 1 4 – 1 0 – – – – – 0 0
1 0 3 1 4 – 2 0 – – – – – 0 0
Order number
1 0 0 3 – 2 4 – 1 – – – – 1 0
N 5 9 5 5 1 0 1 0 0 0 0 0 0 0
N 5 9 5 0 0 0 0 0 0 0 0 0 0 0
EN 105
