Order flexible lead
cover
Accessories

Flexible lead cover

Flexible lead covers for cable inlet ("Installing and connecting the cable", page 61) from the door leaf to
the frame profile (or the wall) are not included in the scope of supply of the electric multi-point lock 819N. A
lead cover can be ordered separately:
effeff – flexible lead cover 10312-10
Concealed installation in the door frame
effeff – flexible lead cover 10312-20
Concealed installation in the door frame, with integrated cable tracking
effeff – flexible lead cover 10314-10
Concealed installation in the door frame, with clamp plug connection on both ends and flexible anti-tear
cable
effeff – flexible lead cover
Concealed installation in the door frame, with clamp plug connection on both ends and flexible anti-tear
cable

Electrical accessories

Identifier Description
Mains adapter Power supply 24 V / 1 A continuous current stabi-
1003-24-1 lised output voltage
For installation
· in junction boxes or
· on top-hat rail
Cable The maximum cable length depends on the wire
cross-section and the output power on the mains
adapter ("Technical data", page 69)
OneSystem Universal Interconnectivity Interface: For provision
IO module N5950 of additional functions such as monitoring con-
tacts, time settings and additional door contacts
1 0 3 1 2 – 1 0 – – – – – 0 0
1 0 3 1 2 – 2 0 – – – – – 0 0
1 0 3 1 4 – 1 0 – – – – – 0 0
1 0 3 1 4 – 2 0 – – – – – 0 0
Order number
1 0 0 3 – 2 4 – 1 – – – – 1 0
N 5 9 5 5 0 0 1 0 0 0 0 0 0 0
N 5 9 5 0 0 0 0 0 0 0 0 0 0 0
