22.5.12.

Watchdog Configuration Submenu

Feature
POST
Watchdog
Runtime
Watchdog
Delay
Event 1
Event 2
Event 3
DLoG IPC 7/215
Options Description
Disabled Select the timeout value for the POST
30sec watchdog.
1min
2min The watchdog is only active during the
5min power-on-self-test of the system and
10min provides a facility to prevent errors during
30min boot up by performing a reset..
Disabled Selects the operating mode of the runtime
One time trigger watchdog.
Single Event This watchdog will be initialized just before
Repeated Event the operating system starts booting.
If set to One time trigger the watchdog
will be disabled after the first trigger.
If set to Single event , every stage will be
executed only once, then the watchdog will
be disabled.
If set to Repeated event the last stage will
be executed repeatedly until a reset occurs.
see Post Select the delay time before the runtime
Watchdog watchdog becomes active. This ensures
that an operating system has enough time
to load.
NMI Selects the type of event that will be
ACPI Event generated when timeout 1 is reached. For
Reset more information about ACPI Event see
Power Button section 9.4.1 of this user's guide.
Disabled Selects the type of event that will be
NMI generated when timeout 2 is reached.
ACPI Event
Reset
Power Button
Disabled Selects the type of event that will be
NMI generated when timeout 3 is reached.
ACPI Event
Handbuch
Anhang F: BIOS
189
