18.2.8. CompactFlash Steckverbinder

Ausführung: Stiftsockel 2-reihig, 50pol., Motherboard Referenz P10
Pin-Nr.
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
DLoG IPC 7/215
Signal
GND
D4
D6
/CS0-
GND
GND
VCC0
GND
GND
A1
D0
D2
n.c.
D11
D13
D15
n.c.
IOWR-
INTRQ
CSEL-
RESET-
NC/INPACK-
DASP-
D8
D10
n.c. = not connected
Handbuch
Anhang B: Anschlussbelegung (Pins)
Pin-Nr. Signal
2 D3
4 D5
6 D7
8 GND
10 GND
12 GND
14 GND
16 GND
18 A2
20 A0
22 D1
24 n.c.
26 n.c.
28 D12
30 D14
32 CS1-
34 IORD-
36 WE-
38 VCC1
40 n.c.
42 IORDY
44 VCC/REG-
46 PDIAG-
48 D9
50 GND
