Anhang F: BIOS
Feature
Local Flat
Panel Scaling
178
Options
XGA 2x18 (007h)
XGA 1x24 (008h)
XGA 2x24 (012h)
SXGA 2x24 (00Ah)
UXGA 2x24 (00Ch)
Customized EDID™ 1
Customized EDID™ 2
Customized EDID™ 3
Centering,
Expand Text,
Expand Graphics,
Expand Text &
Graphics
Handbuch
Description
an EDID data set via the video I²C bus.
Note: Customized EDID™ utilizes an
OEM defined EDID™ data set stored
in the BIOS flash device.
VGA = 640x480
SVGA = 800x600
XGA = 1024x768
SXGA = 1280x1024
Use the following settings for:
VGA 1x18 (013h)
for Hosiden HLD1045AE
SVGA 1x18 (004h)
for Optrex T-51944D104J-FW-A-
AA,NEC NL8060BC31-28D and AUO
G104SN03 V0
XGA 1x18 (006h)
for NEC NL10276BC24-13
XGA1x24 (008h)
for CMO G150X1-L01
Select whether and how to scale the
actual video mode resolution to the
local flat panel resolution.
DLoG IPC 7/215
