Anhang B: Anschlussbelegung (Pins)
18.2.16.
VGA Interface (for service purposes only)
Ausführung: AMP MicroMatch 2x5pol. , Referenz P18
146
Pin-Nr.
Signal
1
GND
2
VGA_R
3
VGA_G
4
VGA_B
5
GND
6
GND
7
VGA_HSY
8
VGA_VSY
9
+5 V
10
+5 V
