Anhang B: Anschlussbelegung (Pins)
18.2.12.
Touch Steckverbinder für resistiven Touch-Screen
Ausführung: Hirose DF13, 8pol., Motherboard Referenz P20
Pin-Nr.
1
2
3
4
140
Signal
IN_TS_Y−
IN_TS_SY−
IN_TS_SY+
IN_TS_Y+
Handbuch
Pin-Nr.
Signal
5
IN_TS_X+
6
IN_TS_SX+
7
IN_TS_SX−
8
IN_TS_X−
