Feature
LBA/Large
Mode
Block (Multi-
Sector
Transfer)
PIO Mode
DMA Mode
S.M.A.R.T
32Bit Data
Transfer
DLoG IPC 7/215
Options Description
drive is attached. The BIOS will not attempt
to search for other types of IDE disk drives.
ARMD specifies an ATAPI Removable
Media Device. This includes, but is not
limited to ZIP and LS-120.
Disabled Set to AUTO to let the BIOS auto detect
LBA mode control. Set to Disabled to
Auto
prevent the BIOS from using LBA mode.
Disabled Set to AUTO to let the BIOS auto detect
Auto device support for multi sector transfer. The
data transfer to and from the device will
occur multiple (the number of sectors, see
above) sectors at a time.
Set to Disabled to prevent the BIOS from
using block mode. The data transfer to and
from the device will occur one sector at a
time.
Auto Set to AUTO to let the BIOS auto detect the
0, 1, 2, 3, 4 supported PIO mode.
Auto Set to AUTO to let the BIOS auto detect the
SWDMA0, 1, 2 supported DMA mode.
MWDMA0, 1, 2 SWDMA = Single Word DMA
UDMA0, 1, 2, 3, MWDMA = Multi Word DMA
4, 5, 6 UDMA = Ultra DMA
Auto Set to AUTO to let the BIOS auto detect
Disabled hard disk drive support.
Enabled Set to Disabled to prevent the BIOS from
using SMART feature.
Set to Enabled to allow the BIOS to use
SMART feature on supported hard disk
drives.
Disabled Enable/Disable 32-bit data transfers on
Enabled supported hard disk drives.
