22.5.3. Graphics Configuration Submenu
Feature
Primary Video
Device
Internal VGA
Mode Select
DVMT Mode
Select
DVMT/FIXED
Memory
Boot Display
Device
Local Flat
Panel Type
DLoG IPC 7/215
Options
Internal VGA
PCI /Int.VGA
Disabled
Enabled, 1MB
Enabled, 8MB
Fixed Mode
DVMT Mode
Combo Mode
64MB
128MB
Auto
CRT only
SDVO only
CRT + SDVO
LFP only
CRT + LFP
Auto
VGA 1x18 (002h)
VGA 1x18 (013h)
SVGA 1x18 (004h)
XGA 1x18 (006h)
Handbuch
Description
Select primary video adapter to be
used during boot up.
This option allows you to disable the
internal VGA controller or enable it with
1MB or 8MB initial frame buffer size.
Select the DVMT mode to be used by
the DVMT graphics driver.
Fixed Mode: The amount of DVMT
memory selected is always allocated
by the DVMT graphics driver.
DVMT Mode: The DVMT driver only
allocates as much memory as required
for the current video mode but may
allocate memory up to the limit
specified in the following node.
Combo Mode: The DVMT graphics
driver allocates at least 64MB but may
allocate up to 128MB if required.
DVMT = Dynamic Video Memory
Technology
Amount of DRAM the DVMT graphics
driver can or will allocate (depends on
DVMT mode selected).
Select the display device(s) used for
boot up.
LFP = Local Flat Panel (LVDS)
Note: Auto feature only works with a
DDC compatible CRT monitor.
Select a predefined LFP type or
choose Auto to let the BIOS
automatically detect and configure the
attached LVDS panel.
Auto detection is performed by reading
Anhang F: BIOS
177
