Anhang F: BIOS

22.3. Setup Menu and Navigation

The BIOS setup screen is composed of the menu bar and two main frames. The menu
bar is shown below. The left frame displays all the options that can be configured in the
selected menu. Grayed-out options cannot be configured. Only the blue options can be
configured. When an option is selected, it is highlighted in white.
The right frame displays the key legend. Above the key legend is an area reserved for
text messages. These text messages explain the options and the possible impacts when
changing the selected option in the left frame.
The setup program uses a key-based navigation system. Most of the keys can be used
at any time while in setup. The table below explains the supported keys:
Key
← → Left/Right Select a setup menu (e.g. Main, Boot, Exit).
↑ ↓ Up/Down
+ - Plus/Minus
Tab
F1
F2/F3
F7
F9
F10
END
ESC
ENTER
170
Description
Select a setup item or sub menu.
Change the field value of a particular setup item.
Select setup fields (e.g. in date and time).
Display General Help screen.
Change Colors of setup screen.
Discard Changes.
Load optimal default settings.
Save changes and exit setup.
This button can be pressed repeatedly immediately after power is
initiated so that the manufacturer default settings can be loaded.
This is helpful when a previous BIOS setting is no longer desired.
Discard changes and exit setup.
Display options of a particular setup item or enter sub menu.
