DLoG IPC 7 Handbuch Seite 198

Anhang F: BIOS
22.5.7.1. Primary/Secondary IDE Master Submenu
Feature
Device
Vendor
Size
LBA Mode
Block Mode
PIO Mode
Async DMA
Ultra DMA
S.M.A.R.T
Type
182
Options Description
no option Displays the type of drive detected. he
'grayed-out' items below are the IDE disk
drive parameters taken from the firmware of
the IDE disk
no option Manufacturer of the device.
no option Total size of the device.
supported Shows whether the device supports Logical
not supported Block Addressing.
number Block mode boosts IDE performance by
of sectors increasing the amount of data transfered.
Only 512 byte of data can be transfered per
interrupt if block mode is not used. Block
mode allows transfers of up to 64 kB per
interrupt.
0, 1, 2, 3, 4 IDE PIO mode programs timing cycles
between the IDE drive and the
programmable IDE controller. As the PIO
mode increases, the cycle time decreases.
no option This indicates the highest Asynchronous
DMA Mode that is supported.
no option This indicates the highest Synchronous
DMA Mode that is supported.
no option Self-Monitoring Analysis and Reporting
Technology protocol used by IDE drives of
some manufacturers to predict drive
failures.
Not Installed Sets the type of device that the BIOS
Auto attempts to boot from after the POST has
CD/DVD completed. Not Installed prevents the BIOS
ARMD from searching for an IDE disk. Auto allows
the BIOS to auto detect the IDE disk drive
type.
CD/DVD specifies that an IDE CD/DVD
