Anhang F: BIOS

22.5.6. I/O Interface Configuration Submenu

Feature
Onboard Audio
Controller
Onboard
Ethernet
Controller
Serial Port 1/2
Configuration
Parallel Port
Address
Serial Port 3/4
Configuration
180
Options Description
Azalia Configure onboard audio controller for
AC97 AC'97 or Azalia (Intel High Definition
Disabled Audio) mode.
Note: Azalia mode requires an external
Azalia codec.
Enabled Enable / Disable the ICH6M onboard
Disabled Ethernet controller.
Disabled Specifies the I/O base address and IRQ of
3F8/IRQ4 serial port 1/2.
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled Specifies the I/O base address used by the
378 parallel port.
278
3BC
Disabled Specifies the I/O base address and IRQ of
3F8/IRQ11, serial port 3/4.
2F8/IRQ10,
3E8/IRQ11,
2E8/IRQ10,
3F8/IRQ10,
2F8/IRQ11,
3E8/IRQ10,
2E8/IRQ11
Handbuch DLoG IPC 7/215
