Anhang F: BIOS
Feature
Terminal Type ANSI
VT-UTF8
Combination
Key Support
Sredir Memory
Display Delay
22.5.11.

Hardware Monitoring Submenu

Feature
H/W Health
Function
Board
Temperature
CPU
Temperature
Fan1 Speed
VcoreA
VcoreB
+3.3Vin
+5Vin
VBAT
188
Options Description
redirected, but Serial Redirection will
terminate when the OS loads.
Select the target terminal type.
VT100 Escape sequences representing keystrokes
VT-UTF8 are sent to the remote terminal based on
these settings.
Disabled This option enables VT-UFT8 combination
Enabled key support for ANSI/ VT100 terminals.
No Delay Set the delay in seconds to display memory
Delay 1 Sec information if serial redirection is enabled.
Delay 2 Sec
Delay 4 Sec
Options
Disabled Enable hardware health monitoring device
Enabled and display the readings.
no option Current board temperature.
no option Current processor die temperature.
no option Current FAN speed.
no option Current Core A reading.
no option Current Core B reading.
no option Current 3.3V reading.
no option Current 5V reading.
no option Current VBAT reading.
Handbuch
Description
DLoG IPC 7/215
