18.2.2.
Eingangsspannungssteckverbinder
Ausführung: Stiftleiste 1-reihig, 3,96mm Raster, 4pol., Motherboard Referenz P1
18.2.3.
Zündungssignalsteckverbinder
Ausführung: AMP Quick Stiftleiste, 5pol., Motherboard Referenz P3
DLoG IPC 7/215
Pin-Nr.
Signal
1
+12V
2
+12V
3
GND
4
GND
Pin-Nr.
Signal
1
IGNITEP
2
DCM
3
n.c.
4
n.c.
5
SUPP_LP
6
VP12_SB
7
GND
8
GND
9
SDAacc
10
SCLacc
Handbuch
Anhang B: Anschlussbelegung (Pins)
133
