Read all of Manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings

OPERATING THE VEHICLE

Improper use of the vehicle or the lack of proper mainte-
nance may result in damage or decreased performance.
Read and understand the following warnings before
attempting to operate the vehicle.
To reduce the possibility of severe injury or
death resulting from loss of vehicle control, the
following warnings must be observed:
When driving vehicle, consider the terrain,
traffic conditions and the environmental fac-
tors which effect the terrain and the ability to
control the vehicle.
Use extra care and reduced speed when
driving on poor surfaces, such as loose dirt,
wet grass, gravel, etc.
S t a y i n d e s i g n a t e d a r e a s a n d a v o i d
extremely rough terrain.
Maintain a safe speed when driving down
hill. Use service brake to control speed
when traveling down an incline. A sudden
stop or change of direction may result in
loss of control.
To prevent loss of control, do not move the
direction selector of a PDS vehicle while the
vehicle is in motion. Moving the selector will
result in a sudden slowing of the vehicle and
the beeping of a warning device.
Slow down before and during turns. All turns
should be made at reduced speed.
Never drive vehicle up, down, or across an
incline that exceeds 14° (25% grade).
To reduce the possibility of severe injury or
death resulting from improper vehicle opera-
tion, the following warnings must be observed:
Refer to GENERAL SPECIFICATIONS for
seating capacity.
Depressing accelerator pedal will release
OPERATION AND SERVICE INFORMATION

PRECISION DRIVE SYSTEM

Precision Drive System™ (PDS) vehicles are operated in
one of four modes or "performance options". All options
have standard features that control, protect and diagnose
the vehicle.
PDS vehicles operate only when the Run - Tow/Maintenance
switch is in the 'RUN' position. (Ref Fig. 8 on page 4)

Performance Options

The options are defined as follows:
Performance Option
Owner's Manual and Service Guide
foot operated park brake and may cause
inadvertent vehicle movement. Turn the key
to the 'OFF' position whenever the vehicle is
parked.
To prevent inadvertent movement when the
vehicle is to be left unattended, engage the
park brake, move direction selector to neu-
tral position, turn key to 'OFF' position and
remove key.
Make sure that the direction selector is in
correct position before attempting to start
the vehicle.
Always bring the vehicle to a complete stop
before shifting the direction selector.
Do not take vehicle out of 'gear' while in
motion (coast).
Check the area behind the vehicle before
operating in reverse.
All occupants must be seated. Keep entire
body inside vehicle and hold on while vehi-
cle is in motion
Top Speed
13.5 mph
1. No Plug
(22 kph)
13.5 mph
2. Blue Plug
(22 kph)
15 mph
3. Yellow Plug
(24 kph)
15 mph
4. Red Plug
(24 kph)
Fig. 13 Performance Options
™
Pedal-Up
Braking Strength
Heavy
Mild
Heavy
Mild
Page 7
