MCW-D 200 – Charger
7.2

Charging Process

1. Connect the charger to AC power and switch it on. The LED on the switch will illuminate.
2. Put the switched-off microphone units into the charging compartments. If microphone units are switched on, they are switched off auto-
matically. When the microphone units are used again, they must be switched on.
3. The charging process is indicated by the green LEDs on the outside.
a) ___ ___ ___ __ LED is flashing slowly:
b) _________________ LED illuminates permanently:
c) - - - - - - - - - - - - - - LED is flashing very rapidly:
d) LED is off:
e) . . . . . . . . LED flashes rapidly:
f) . - . - . - . - . - . - . - . LED long flash/short flash:
LED
Note
• If an error has occured, try to start the charging process once again. If the LEDs are still flashing rapidly, please contact your
beyerdynamic dealer.
• It is normal that the rechargeable batteries are heated up during the charging process.
• Clean the charging contacts with spirit or isopropyl alcohol from time to time.
• If you use the MCW-D system only every few weeks, you should disconnect the charger from the mains and recharge the rechargeable
batteries of the microphone units right before the meeting.
7.3

Forming Mode

The LE-D 10 charging units are equipped with a forming mode for the rechargeable batteries inside the microphone units. The batteries are
formed and charged at the factory. If you have not used the microphone units for several months and repeated charging and discharging
procedures did not help to create a satisfying operating time of the rechargeable batteries, you should form the batteries before you set up
the microphone units. Please proceed as described in the following:
• First of all remove all microphone units from the charging compartments.
• After switching on the charger press the buttons in the bottom of the two furthest charging compartments (next to the contact pins in the
round gap).
• Pressing one of these buttons will activate the forming mode for 5 charging compartments. The LEDs will flash rapidly.
• Then put the microphone units into the charging compartments. The LEDs will flash short and long.
• When the green LEDs are permanently on, then the battery is full.
CAUTION:
• Only form empty batteries, but never full batteries! Do not switch off the charging unit during the forming mode, as this will
interrupt the forming mode.
• The forming mode will be terminated automatically when the microphone units are fully charged or when the charger is switched
off.
• If the forming mode does not help to achieve a satisfying operating time of the rechargeable battery of the microphone unit, the
rechargeable battery is exhausted and must be replaced. The lifetime of the rechargeable battery depends on maintaining the
mentioned recommendations. Therefore, the warranty does not include rechargeable batteries.
Battery is charged
Battery is full
Error
No microphone unit is inserted into charging compartment
or has no contact
Forming mode
Charging in the forming mode
68
