MCW-D 200 – Microphone Units
5.7

Manual Operating Mode

Delegate
(7)
(8)
MCW-D 2673
(3)
5.8

Request-To-Talk Mode without external PC or Control

Delegate
(7)
(8)
MCW-D 2673
(3)
Chairman
• Press the microphone button (8) to switch the gooseneck microphone on.
• Red ring of the gooseneck
microphone is illuminated
and the LED (7) or (3) is
illuminated green: The microphone is ready for talking.
• Using the standard version of the MCW-D 200 control unit 4 participants
(7)
(e.g. 3 delegates and 1 chairman) can speak simultaneously. Using additional
PCBs inside the MCW-D 200 up to 7 participants (6 delegates and 1 chairman)
can speak simul taneously.
(8)
Chairman • The request-to-talk is registered in the system by pressing the microphone
button (8) of the delegate microphone unit.
• The allocation is made with the function button (10) of the chairman micro-
phone unit. The function button (10) and the request-to-talk mode have to
be configured with the MCW-D 200 Editor software before. Please refer also
to the appropriate manual.
• The LED (7) or (3) of the delegate unit is illuminated to indicate the request-
to-talk.
• If you press the microphone button (8) again the request-to-talk is cleared.
The LED (7) or (3) goes out.
• The chairman can clear the request-to-talk list by pressing the "Clear"-
button (9).
(9) (10)
Important:
• If the number of open microphones is reached, a microphone
can only be switched on manually when another microphone
unit has been switched off.
62
