RayTek MI3 Betriebsanleitung Seite 124

ASCII Programmierung
Description Char
Box special DS
Box Status Code EC
External module EM
Presel. Emissivity EP
Pointer
Emissivity Source ES
Presel. Emissivity Value EV
Valley hold time F
2
Flicker Filter FF
Average time G
3
Head Address HA
Connected heads HC
Registered heads HCR
Head Status Code HEC
Box Status Codes (read only):
1
Self-test error
Box ambient temperature out of range
Sensing head communication error
Parameter error
Register write error
Analog module error
Profinet ready
setting average / peak / valley / advanced hold cancels all other hold modes
2
setting average / peak / valley / advanced hold cancels all other hold modes
3
Head Status Codes (read only):
4
Temperature unit
Object temperature out of range
Ambient temperature out of range
Parameter error for a command
Register write error
Self-test error
Head not connected
Ambient temperature compensation
Head access error
Object temperature out of range
Ambient temperature out of range
124
Format P B S N Legal Values
string  
EC 
16 bit hex
?EM 
nEP 
integer
nES  
integer
nEV
 
float
nF     0.0 - 998.9 s
float
nFF
integer
nG     0 – 999.0 s
float
nHA

string 
string  
nHEC

16 bit hex
BIT0
BIT1
BIT2
BIT3
BIT4
BIT5
BIT6
BIT0 // 0 = °C, 1 = °F
BIT1 // 1 = out of range
BIT2 // 1 = out of range
BIT3 // 1 = error
BIT4 // 1 = error
BIT5 // 1 = error
BIT6 (ab Rev. 2.20, not for Profibus communication boxes)
BIT7 // 0 = off, 1 = on
BIT8 (ab Rev. 2.20, not for Profibus communication boxes)
BIT9 (ab Rev. 2.20, not for Profibus communication boxes)
BIT10 (ab Rev. 2.20, not for Profibus communication boxes)
Rev. G1 Nov 2016
e.g. !DSRAY (read only)
hex value of Status Code
1
0 – no module
2 – 2 channels
4 – 4 channels
(analog outputs)
0 - 7
I = Emissivity from Internal
(by command)
E = Emissivity from
External analog input
(0V - 5V)
D = digital selected FTC1-3
0.1 - 1.1
(999 = )
0...32768
1 – 9
e.g. !HC – no heads
!HC1 2 3 7 8
e.g. !HCR – no heads
!HCR1 2 3 7 8
HCR=0 –> new registration
hex value of Status Code
4
Factory default Head /
Box
Set at B
production
B
B
0 H
I H
H
0.0 s H
0 (LT, G5) H
3000 (1M, 2M)
0.0 s H
B
B
B
H
MI3
