RayTek MI3 Betriebsanleitung Seite 102

Modbus
Start Size Modbus Access Data
address [bits]
90 16 holding register short
100 8 discretes input
110 8 discretes input
120 16 holding register short
130 16 holding register short
410 32 input register
420 32 input register
430 16 input register
5<k>0 16 holding register short
5<k>1 16 holding register short
5<k>2 16 holding register short
5<k>3 32 holding register float
5<k>5 32 holding register float
5<k>7 32 holding register float
102
Content
Type
Switch panel lock
bit field Get connected heads
bit field Get registered heads
Laser control (only with
laser)
Relay alarm output
control
float analog input 1 value
float analog input 2 value
short Trigger
analog output k mode
analog output k source head number or 0:
analog output k source
parameter
analog output k fixed
temp. value
analog output k bottom
temp. value
analog output k top
temp. value
Rev. G1 Nov 2016
Values
0: unlocked, 1: locked
bit 0: head 1 ..
bit 7: head 8
bit high: head connected
bit low: head disconnected
bit 0: head 1 ..
bit 7: head 8
bit high: head registered
bit low: head not registered
0: off, 1: on
0: off
1: on
2: norm. open
3: norm. closed
0 .. 5 V
0 .. 5 V
0: off
1: on
5: TCJ
6: TCK
7: TCR
8: TCS
9: 0...5 V
10: 0...10 V
99: disable (tristate)
fixed value from 5<k>3
1: internal temp. of 5<k>1
2: object temp. of 5<k>1
value within range set in address
5<k>0
device bottom temp. .. device top temp. L<k>O
device bottom temp. .. device top temp. H<k>O
MI3[M]
command
J
HC
HCR
XL
KB
TV1I
TV2I
XT
XO<k>O
O<k>O
O<k>O
-
MI3
