8.2 Initial start-up with mains water connection
8.2.1 Connecting and switching on the machine
1. Plug the mains plug into the socket.
2. Press the on/off button (2, Fig. 8).
The LED ring of the on/off button lights up and the "Fill" icon appears on
¾
the display.
8.2.2 Filling the boiler with water (fill mode)
1. Open the flow control (4, Fig. 8) by at least one turn (see Chapter 5.2.4,
„Flow control").
2. Place a receptacle under the brew group (5, Fig. 8). The opening of the
receptacle should be at least as big as the brew group.
3. Move the brew lever into the drawing position (see Chapter 5.2.3,
„Operating levers").
The pump starts to fill the brew boiler.
¾
4. Leave the brew lever in the drawing position for at least 30 seconds.
When water comes out of the brew group, this means that the brew
¾
boiler is full.
5. Move the brew lever into the starting position (see Chapter 5.2.3,
„Operating levers").
The "Fill" icon disappears from the display and the steam boiler is filled.
¾
6. Wait until you cannot hear any more pump noise.
The steam boiler is full and the machine starts to heat up the boilers.
9
The "Heating Up" icon appears on the display. After the boilers have
heated up, the brew temperature is shown on the display. The machine
is ready to use.
8.2.3 Rinsing the machine
Rinse the machine with 5 - 8 liters of water before preparing your first
espresso.
1. Switch off the heated-up machine using the on/off button.
The LED ring goes out.
¾
2. Drain water via the hot water wand (see Chapter 11.6, „Emptying the
boiler").
3. Switch on the machine using the on/off button.
The LED ring lights up.
¾
4. Allow the machine to heat up.
5. Repeat this procedure three times.
6. With the machine switched on, empty the remaining quantity of water
via the brew group.
