1. Insert the blind filter.
2. If the drain pan is installed (see Chapter 7.4.4, „Installing the drain pan"),
remove the rubber stopper in the middle of the drip tray.
3. Insert the grid (2, Fig. 6) in the drip tray (3, Fig. 6).
4. Place the drip tray with the recesses on the underside onto the holder
on the machine and push it in until it latches in place.
7.5.2 Installing the cup raiser
When using espresso cups, it is recommended that you install the cup raiser
(1, Fig. 6) in order to prevent the espresso from splashing out.
1. Place the cup raiser on the drip tray.
2. Position it so that the edges of the cup raiser latch into the drip tray
grid.
3. Make sure that the cup raiser does not wobble or tilt, but rather is
securely latched in place.
7.5.3 Installing the water filter
The water filter can optionally be acquired (see Chapter 12.1, „Spare parts and
accessories"). Install it as follows:
Fig. 7
Plan view of water tank
1 Position of water filter adapter
1. Unpack and prepare the filter cartridge according to the manufacturer's
specifications.
2. Remove the cup tray from the top of the machine.
3. Insert the filter cartridge into the water filter adapter (1, Fig. 7) in the
water tank so that it latches in place.
4. Install the cup tray.
