72 | LA14
Schedule to EU-Type Examination Certificate TÜV 15 ATEX 143740 X Issue 00
(16) Drawings and documents are listed in the ATEX Assessment Report No. 23 203 334889.
(17) Specific Conditions for Use
1.
The duty cycle is max. 20% (4 min drive and 16 min rest).
2.
Ambient temperature area is specified to -25 °C...+65 °C.
3.
The power supply cable is of special design fulfilling IP 6X ingress protection. The
cable can be delivered in different lengths. Only cables delivered by LINAK A/S shall
be mounted.
4.
The connection between the actuator and the rest of the machine/device shall be
conductive, and furthermore the application shall be grounded in order to remove
any Electro Static Discharge. This counts for both of the actuator's fixation points
(Back Fixture and Piston Rod Eye).
5.
The cable is not UV-resistant and shall be protected from direct sunlight.
6.
The supply shall be protected by a fuse according to the electrical data.
7.
The Linear Actuator has to be installed in such a way, that highly effective potential
electrostatic charges are prevented. The cleaning of the Linear Actuator shall be done
only with a damp cloth.
(18) Essential Health and Safety Requirements
No additional ones
P17-F-011
- End of EU-Type Examination Certificate -
This certificate may only be reproduced without any change, schedule included.
Excerpts or changes shall be allowed by the TÜV NORD CERT GmbH
Rev. 02/11.21
Page 3/3
