Product, parts and accessories
See Care, cleaning and storage: Removing and installing parts to find out how
everything fits together.
Top of lid
Bottom of lid
Instant Tip: Stand the lid up in the base handles to keep it off your
countertop! Insert the left or right lid fin into the corresponding
slot in the multicooker base handles to stand it up and save some
space.
8 | support@instantpot.co.uk | +44 (0) 3331 230051
Duo-Plus-EU_Full_Manual-2021-03-11.indd 8 Duo-Plus-EU_Full_Manual-2021-03-11.indd 8
Illustrations in this document are for reference only and may differ
from the actual product. Always refer to the actual product.
Steam release valve
Float valve
Steam release switch
Handle
Lid fins
Lid position marker
Locking pin
Silicone cap
(bottom of float valve)
Anti-block shield
Steam release pipe
(beneath anti-block shield)
Sealing ring rack
Sealing ring
