Danfoss VLT Lift Drive LD 302 Kurzanleitung Seite 93

PM-Motortyp
Parameter-Nr., Beschreibung und Motordaten
Motor-
Strom
ZA=Ziehl ABEGG-
Motor
M37-Te-Stand
M38-GLAT
M39-ZA-160.20-
3,3kW-240 UPM
M40-ZA-160.20-
5,2kW-384 UPM
M41-ZA-160.30-
2,8kW-192 UPM
M42-ZA-160.30-
3,5kW-240 UPM
M43-ZA-160.30-
4,4kW-300 UPM
M44-ZA-160.30-
5,6kW-384 UPM
M45-ZA-160.40A-
5,2kW-192 UPM
M46-ZA-160.40A-
6,5kW-240 UPM
M47-ZA-160.40A-
8,2kW-300 UPM
M48-ZA-160.40A-
10,5kW-384 UPM
M49-ZA-200.15C-20-
2,5kW-96 UPM
M50-ZA-200.15C-20-
4,4kW-168 UPM
M51-ZA-200.15C-20-
4,3kW-186 UPM
M52-ZA-200.15C-20-
5kW-192 UPM
M53-ZA-200.15C-20-
6,8kW-258 UPM
M54-ZA-200.15C-20-
7,9kW-300 UPM
M55-ZA-200.20C-20-
3,3kW-96 UPM
M56-ZA-200.20C-20-
4,1kW-120 UPM
M57-ZA-200.20C-20-
5,8kW-168 UPM
M58-ZA-200.20C-20-
6,6kW-192 UPM
M59-ZA-200.20C-20-
8,9kW-258 UPM
M60-ZA-200.20C-20-
10,4kW-300 UPM
M61-ZA-200.30C-20-
4,8kW-96 UPM
M62-ZA-200.30C-20-
6kW-120 UPM
M63-ZA-200.30C-20-
6,7kW-168 UPM
M64-ZA-200.30C-20-
8,4kW-168 UPM
M65-ZA-200.30C-20-
9,6kW-192 UPM
Quick Guide VLT® Lift Drive LD 302, Rev. 3.1
Kurzanleitung VLT Lift Drive LD302
1-24 1-25
Motor- Nennmoment
Nenndrehzahl
[A] [U/min]
1600 150
2250 180
830 240
1220 384
1050 192
1300 240
1600 300
1950 384
1400 192
1650 240
2000 300
2500 384
900 96
1350 168
1150 186
1500 192
1900 258
2050 300
1100 96
1280 120
1650 168
1900 192
2500 258
2850 300
1450 96
1700 120
1700 168
2200 168
2450 192
Classified as Business
1-26 1-30
Statorwider- Induktion
[Nm] stand (Rs) d-Achse
[Ohm]
4430 13800
3300 6000
1300 33600
1300 15800
1950 29800
1950 20700
1950 13900
1950 9100
2600 22100
2600 15600
2600 10500
2600 6700
2500 62200
2500 27600
2200 27000
2500 22900
2500 13700
2500 11300
3300 46600
3300 34600
3300 20800
3300 15800
3300 9200
3300 7100
4750 30900
4750 22500
3800 15800
4750 13500
4750 10500
1-37 1-39
Motorpolzahl Gegen-EMK
(Ld) 1000 U/min
[mH]
72 24
43 40
167 20
76 20
167 20
116 20
78 20
51 20
133 20
93 20
64 20
40 20
371 20
164 20
168 20
133 20
81 20
66 20
308 20
227 20
137 20
105 20
61 20
47 20
234 20
17 20
122 20
101 20
79 20
93
1-40
bei
[V]
1810
1105
908
626
1126
937
796
626
1162
973
807
640
1766
1267
1060
1063
818
744
1874
1629
1256
1099
831
732
2054
1730
1318
1328
1180
