Owner's Guide
V. Operations and Controls
Control Panel
Shot switch
5.1. Powering ON and OFF
• The battery charge level display:
Three green lights indicate a fully charged LED curing light.
One or two green lights indicate the curing light is not
fully charged. The unit beeps one time after displaying the
battery charge level indicating the LED is ready to use.
• Power ON: Press the Shot switch or the Mode switch to
activate the S.P.E.C 3
• Power OFF: S.P.E.C. 3
automatically after 5 minutes if no operation is detected
(Sleep mode).
• If the curing light is in "Sleep" mode, pressing any
switch will "awaken" the light to the curing mode last
used.
5.2. Basic Controls
• Mode switch:
- Press the Mode switch quickly to select various time
settings.
- Press and hold the Mode Switch for 3 seconds to
switch between curing modes. Two beeps are emitted.
Mode switch
® Curing Light.
® LED Curing Light turns off
EN
• Shot switch:
- Press the Shot switch to start the selected curing
program.
- Press the Shot switch during operation to stop the
program in progress.
5.3. Mode selection
• 3K Mode / Ortho Mode: When selected, the LED
display turns to ORANGE color. The output will be
3000 mW/cm².
Standard Mode: When selected, the LED display turns
•
to GREEN color. The output will be 1600 mW/cm².
Press and hold the Mode switch for 3 seconds to change
curing mode (GREEN and ORANGE light changes alternately).
5.4. Polymerization time setting
3K / Ortho Mode: Quickly press the Mode switch
•
sequentially on ORANGE light to toggle the light through
the 4 time settings
(1sec. - 2sec - 3sec. - Ortho Mode).
Ortho Mode (Orange) Recommended for curing a full arch of
orthodontic brackets, or 16 brackets total. When activated, the
light will cure for approximately 3 seconds for each mesial or
distal side. A visual half-second blink and an audible beep will
indicate when each bracket side has been cured.
OM
15 3
10 2
5 1
1 Sec.
OM OM OM
15 3 15 3 15 3
10 2 10 2 10 2
5 1 5 1 5 1
2 Sec. 3 Sec. Ortho
Mode
(ORANGE)
