8
5. Insert the handpiece into the charger base. Verify that the
charger base LED is illuminated orange which indicates
that the device is charging. An illuminated green LED
indicates the light is fully charged.
Charging the battery pack:
• The handpiece should be placed on the charger base
when battery is low or not in use.
• Before using the S.P.E.C. 3
time, please charge its battery for 24 hours.
• Make sure the handpiece is properly connected and
placed on the charger base. Do not force fit.
• When the battery is low or discharged, the handpiece
will not operate or maintain low power output. Place the
handpiece on the charger base immediately for 2-3 hours
before attempting to use.
• Charging in progress: ORANGE light is ON
• Charging complete: GREEN light is ON
NOTE: Do not operate the device while being charged on the
charger base.
4.1. Installation procedure
1. Gently insert the light guide into the opening on the hand-
piece. When light guide is fully inserted, approximately 1mm
of the metal ring will be exposed.
Place the barrier sleeve over the curing light. Put the eye shield
2.
over the end of the light guide drawing the barrier sleeve taut.
Plug the AC power cord into the receptacle in the power
3.
adapter.
Connect the S.P.E.C. 3 ® LED Charger Base to the power adapter.
4.
Insert the plug on the power adapter completely into the wall
electrical outlet.
5. Keep the handpiece on the charger base when not in use.
® LED Curing Light for the first
EN
• If the light or eye shield obstructs view of the
restoration, UV eye protection may be worn as
an alternate means of protection.
• Do not expose the device or the power supply
to extreme temperatures or open fire. Operate
in ambient temperatures. (recommended
temperature: -5°C ~ +40°C (23°F ~ 104°F).
Malfunction may occur.
• The S.P.E.C. 3
function properly if all of its components are
in good operating condition. Check the device
components thoroughly before use.
- Ensure no components are damaged or
deformed.
- Ensure the main plug and the electrical outlet
socket are compatible.
CAUTION
- Check to see if the power cord is damaged.
• When the battery level is critical, the LED display
will turn to ORANGE and start blinking: Please
fully recharge the S.P.E.C. 3
placing the handpiece on the charger base for
2-3 hours. Failure to fully recharge may reduce
battery life.
• Built-in automatic cool-down protection mode:
The S.P.E.C. 3
if its surface temperature is above 45°C (113°F)
for user's safety. The light will flash alternately
between green and orange in the cool-down
protection mode. Place the handpiece into the
charger base and allow the light to cool down
for 5 minutes then try again.
S.P.E.C. 3 ® LED Curing LIght
® LED Curing Light will only
® LED handpiece by
® LED handpiece will not function
